GZ80.01

Technical Air System

Medical Air Plant is designed to provide a continuous supply of medical quality air. Medical air is mainly supplied via a medical gas pipeline system where the air is generated by compressors, dryers and filtration system.
Inspital Medical Air plant with rotary screw compressors can be used in wide capacity range. Compressor capacities varies from 2.2 kW to 37 kW. High quality screw blocks with perfect lubrication systems enable continuous operation, stability and reliability. At technical air solutions offers compressed air dryers with +3-5°C  dew point temperature.
Inspital can offer different capacities according to hospital consumption and bed capacity.

Our experts are ready to offer you the most suitable solutions.

TECHNICAL AIR SYSTEM

Model no Compressor
Capacity
Compressor Type Dryer Capacity Tank Capacity Operating
Temperature
Bed
Quantity
GZ80.01 1x39 m³/h Screw Type 1x50 m³/h 300 L (+10) - (+50) C° 20-50
GZ80.02 2x39 m³/h Screw Type 1x50 m³/h 300 L (+10) - (+50) C° 20-50
GZ80.03 1x84 m³/h Screw Type 1x87 m³/h 500 L (+10) - (+50) C° 50-100
GZ80.04 2x84 m³/h Screw Type 1x87 m³/h 500 L (+10) - (+50) C° 50-100
GZ80.05 1x117 m³/h Screw Type 1x130 m³/h 1000 L (+10) - (+50) C° 100-150
GZ80.06 2x117 m³/h Screw Type 2x130 m³/h 1000 L (+10) - (+50) C° 100-150
GZ80.07 1x168 m³/h Screw Type 1x170 m³/h 1500 L (+10) - (+50) C° 150-200
GZ80.08 2x168 m³/h Screw Type 2x170 m³/h 1500 L (+10) - (+50) C° 150-200
GZ80.09 1x210 m³/h Screw Type 1x283 m³/h 2x1000 L (+10) - (+50) C° 200-250
GZ80.10 2x210 m³/h Screw Type 2x283m³/h 2x1000 L (+10) - (+50) C° 200-250





MEDICAL AIR SYSTEM

MODEL NO COMPRESSOR CAPACITY COMPRESSOR PCS COMPRESSOR TYPE TANK
CAPACITY
MEDICAL
GAS SYSTEM
OPERATING
TEMPERATURE
BED
QUANTITY
GZ80.20 78 m³/h 3 Screw Type 2 x 300 L 2 (+10)-(+50) C° 50-100
GZ80.21 115 m³/h 3 Screw Type 2 x 500 L 2 (+10)-(+50) C° 100-150
GZ80.22 168 m³/h 3 Screw Type 2 x 1000 L 2 (+10)-(+50) C° 150-200
GZ80.23 235 m³/h 3 Screw Type 2 x 1000 L 2 (+10)-(+50) C° 200-250
GZ80.24 276 m³/h 3 Screw Type 2 x 1500 L 2 (+10)-(+50) C° 250-300
GZ80.25 420 m³/h 3 Screw Type 2 x 2000 L 2 (+10)-(+50) C° 300-500
