JK90.50

Probes

Inspital probes are produced according to international standards by using a secial labelling for gases. They are used to supply necessary gases from terminal units to the patient or medical equipments via hose connections or by direct connection to the equipment. Inspital Probes are manufactured in compliance with BS 5682: 1992, DIN 13260, AFNOR NF S 90116

Our experts are ready to offer you the most suitable solutions.

Get an Offer

Manufactured according to BS, DIN & AFNOR standard
Special connections for O2, N2O, AIR 4 and AIR 7
Special labeling for each gas type
Safe hose connection
Made of chrome plated brass material or stainless steel

Angled Probe

		BS 90º	DIN 90º	AFNOR 90º	BS 180º	DIN 180º	AFNOR 180º
Oxygen	Stainless Steel	JK90.50	JK90.51	JK90.52	JK92.50	JK92.51	JK92.52
Oxygen	Brass	JK90.56	JK90.57	JK90.58	JK92.56	JK92.57	JK92.58
Vacuum	Stainless Steel	JK90.60	JK90.61	JK90.62	JK92.60	JK92.61	JK92.62
Vacuum	Brass	JK90.66	JK90.67	JK90.68	JK92.66	JK92.67	JK92.68
Air 4	Stainless Steel	JK90.70	JK90.71	JK90.72	JK92.70	JK92.71	JK92.72
Air 4	Brass	JK90.76	JK90.77	JK90.78	JK92.76	JK92.77	JK902.78
Air 7	Stainless Steel	JK90.80	JK90.81	JK90.82	JK92.80	JK92.81	JK92.82
Air 7	Brass	JK90.86	JK90.87	JK90.88	JK92.86	JK92.87	JK92.88
N2O	Stainless Steel	JK90.90	JK90.91	JK90.92	JK92.90	JK92.91	JK92.92
N2O	Brass	JK90.96	JK90.97	JK90.98	JK92.96	JK92.97	JK92.98
CO2	Stainless Steel	-	JK91.11	JK91.12	-	JK93.11	JK93.12
CO2	Brass	-	JK91.17	JK91.18	-	JK93.17	JK93.18
